【TechnologyParameters】：
1. Type: horizontal roller type, front door feeding method;
2. Rotor diameter: 520±1mm;
3. Drum depth: 315±1mm;
4. Drum volume: 61 L;
5. Number of rotary lifting plates: 3 pieces 120° evenly distributed;
6. Height of the lifting plate of the rotary cylinder: 53±1mm;
7. Outer cylinder diameter: 554±1mm;
8. Display operation: large screen color touch screen operation;
9. Rotation Action:
Normal: Clockwise rotation (12±0.1) s, stop (3±0.1) s; Turn counterclockwise (12±0.1) s, stop (3±0.1) s;
Gentle: turn clockwise (8±0.1) s, stop (7±0.1) s; Counterclockwise rotation (8±0.1) s, stop (7±0.1) s;
Soft: turn clockwise (3±0.1) s, stop (12±0.1) s; Turn counterclockwise (3±0.1) s, stop (12±0.1) s;
10. Speed: When washing: 52rpm digital setting; Dehydration: 300rpm ~ 800rpm digital setting;
11. Water level control: low: 100mm high: 130mm, the water level range can be set 25~200mm;
12. Water temperature setting range: room temperature to 95°C±1°C;
13. Washing program: built-in GB/ISO standard washing program, and 2 sets of programs for users to write their own programs;
14. Water inlet time: ≤2min (water pressure 0.1Mpa);
15. Drainage time: ≤1min;
16. Washing capacity: ≥5kg;
17. Power supply: AC220V±10% 50HZ;
18. Power: 6.5KW;
19. Overall dimensions: 750×840×1260mm;
20. Net weight: 300kg.
【Instrument features:】：
1. This instrument adopts industrial-grade design, computer chip management intelligent control operation, suitable for the demanding requirements of long-term continuous testing;
2. The technical indicators of the instrument fully meet the requirements of the latest version of standards such as ISO6330 and GB/T8629;
3. Adopt full suspension, high shockproof inner cylinder structure design, more stable operation;
4. Imported AC frequency conversion control technology is used to protect the safety and smooth operation of the motor;
5. Large screen color touch screen, Chinese and English graphic operation menu, the display is clearer and more intuitive;
6. Built-in GB national standard, ISO standard and user-written program, with manual mode;
7. Adopt high-precision electronic pressure sensor to ensure accurate and reliable water level;
8. The whole machine is made of high-quality 304 stainless steel, which has a simple and elegant appearance, and is sturdy and durable.
9. Wireless remote control function, mobile APP to monitor the operation of the instrument at all times.
10. Intelligent protection and reminder function, abnormal situation can automatically stop the machine.
11. Wireless network penetration function, can upgrade the update program remotely and wirelessly
12. Multi-functional feeding powder box device, one powder can be washed multiple programs continuously.
