YG028 Automatic Universal Tensile Tester
产品型号
YG028发布时间
2020-07-21企业性质
私有浏览次数
相关产品
RELATED PRODUCTS
YG026T Electronic Fa
型号：YG026T
YS-382B Diaper Perme
型号：YS-382B
详细介绍
【Scope of application】
It is used to measure the fracture strength, elongation at break, tearing, peeling, top breaking, joint slippage, joint strength, cracking, elastic recovery and other mechanical properties of various textiles, nonwovens, leather, rubber, metal and other materials. It also has various test functions such as fixed speed, positioning shift, fixed time, fixed load, and fixed elongation.
【Relevant Standards】
1.Tensile strength (rod method): GB/T3923.1; ISO13934.1; ASTM D5035; (grab method): GB/T3923.2; ISO13934.2; ASTM D5034; 2.Tear strength (tongue-and-gape tear): GB/T3917.2; ISO13937.2; ASTM D2261; (trapezoidal tear): GB/T3912.3; ISO9074.4; ASTM D5587; 3.Thread slippage: GB/T13772.1/2/3; ISO13936.1/2; ASTM D434;4.Peel strength: FZ/T01085; ASTM D2724/3936; AATCC 136; FZ/T80007.1; FZ/T01010; FZ/T60011; 5.Ball penetration: GB/T19976; FZ/T01030; ISO3303; ASTM D3787/6796; 6.Elastic recovery: FZ/T70005; FZ/T70006; BS 4952; 7.Single yarn strength: GB/T3916/14344; ISO2062; ASTM D2256; 8. Other standards: GB/T4689.6; GB/T13763；GB/T13773；GB/T14800；GB/T15788； GB/T16989；FZ/T01031；FZ/T20019；FZ/T60005；FZ/T60006；FZ/T70007；ISO 13935.1/2；ASTM D1683；ASTM D4964；ASTM D5733/5735；BS 3320.
【Meet the standard】
1. Breaking strength (strip method): GB/T3923.1;ISO13934.1;ASTM D5035;
(Sample Capture Method):GB/T3923.2;ISO13934.2;ASTM D5034;
2. Tearing strength (tongue tearing): GB/T3917.2;ISO13937.2;ASTM D2261;
(Trapezoidal tearing):GB/T3912.3;ISO9074.4; ASTM D5587;
3. Suture slip: GB/T13772.1/2/3;ISO13936.1/2;ASTM D434;
4. Peel strength: FZ/T01085; ASTM D2724/3936； AATCC 136；FZ/T80007.1；
FZ/T01010；FZ/T60011
5. Steel ball top breakage: GB/T19976; FZ/T01030； ISO3303； ASTM D3787/6796；
6. Flexible reply: FZ/T70005; FZ/T70006； BS 4952；
7. Single yarn strength: GB/T3916/14344;ISO2062; ASTM D2256；
8. Other standards: GB/T4689.6; GB/T13763; GB/T13773； GB/T14800； GB/T15788；
GB/T16989；FZ/T01031；FZ/T20019；FZ/T60005；FZ/T60006；
FZ/T70007；ISO 13935.1/2；ASTM D1683；ASTM D4964；
ASTM D5733/5735；BS 3320。
【Instrument features】
1. DuPont spraying treatment on the surface of the instrument, anti-scratch, anti-scratch, simple and beautiful;
2. Controlled by Philips 32-bit industrial-grade microcontroller, AD Company in the United States produces 18-bit A/D converter, which has strong anti-interference performance and fast data processing and transmission.
3. The dynamic sampling frequency reaches more than 2000 times/second, and each data peak can be effectively and correctly captured during the test process.
4. LCD touch screen operation, full Chinese menu, built-in printer direct output report, easy operation;
5. Computer online control, dynamic follow-up of instrument working status; Transmit test data and display the tensile curve in real time;
6. Adopt pneumatic clamping, AC servo control system drive, ball screw transmission, ultra-quiet operation;
7. Built-in automatic digital calibration system of force value;
8. Integrated design of test functions, open data connection interface, to achieve multi-purpose of one machine;
9. Force value units: CN, N, Kg and lb, etc.
10. It has a variety of protections such as overload, overstroke and overvoltage to ensure the safe operation of the instrument.
【Technical Parameters】
1. Force measurement range: 50kg, 100kg, 250kg, 500kg, 1000kg; Full scale 1~100%; (Optional)
2. Force measurement accuracy: ≤±0.1% F.S;
3. Drawing speed: 1~1000mm/min (any setting);
4. Recovery speed: 1~1000mm/min (any setting);
5. Sampling frequency: >2000 times/second;
6. Elongation resolution: ≤0.001mm;
7. Effective moving distance: 700mm (pneumatic clamp) 800mm (manual clamp);
8. Power source: AC220V±10%/50Hz
9. Power: 750W;
10. Overall dimensions: 820×630×1800 mm;
11. Net volume: 205Kg.
